ModSecurity Log JSON WAF OWASP CRS for Apache/NGINX
Loki Promtail
/etc/loki/config.yml
This is a complete configuration to deploy Loki backed by the filesystem.
The index will be shipped to the storage via tsdb-shipper.
auth_enabled: false
server: http_listen_port: 3100 grpc_server_max_recv_msg_size: 104857600 # 100 Mb grpc_server_max_send_msg_size: 104857600 # 100 Mb
ingester: chunk_encoding: snappy
ingester_client: grpc_client_config: max_recv_msg_size: 104857600 # 100 Mb max_send_msg_size: 104857600 # 100 Mb
querier: max_concurrent: 8
common: ring: instance_addr: 127.0.0.1 kvstore: store: inmemory replication_factor: 1 path_prefix: /var/loki
query_range: parallelise_shardable_queries: true cache_results: true results_cache: cache: embedded_cache: enabled: true max_size_mb: 100
schema_config: configs:
- from: 2024-10-28 store: tsdb object_store: filesystem schema: v13 index: prefix: index_ period: 24h
storage_config: filesystem: directory: /var/loki/chunks
limits_config: reject_old_samples: true reject_old_samples_max_age: 168h retention_period: 360h max_query_series: 100000 max_query_parallelism: 24 split_queries_by_interval: 15m
default
per_stream_rate_limit: “3MB” per_stream_rate_limit_burst: “15MB”
Data source config
Collector config:
Upload an updated version of an exported dashboard.json file from Grafana
| Revision | Description | Created | |
|---|---|---|---|
| Download |
Get this dashboard
Import the dashboard template
or
