Cloud Intelligence™ data source for Grafana

Visualize your multicloud cost analytics from Cloud Intelligence™ directly in Grafana. The plugin queries the DoiT API directly, with no data export or sync required, across AWS, Google Cloud, Azure, Oracle Cloud and over 40 additional integrations.

Features

• Saved reports: Run any Cloud Analytics report from your DoiT Console and render its results as Grafana time series, tables, or treemaps.
• Ad-hoc queries: Build cost queries in Grafana — pick a metric (cost, usage, or savings), a time interval, and the dimensions to group by (service, project, SKU, labels, …), without creating a report in the DoiT Console first.
• Grafana time range: Report queries can follow the dashboard time picker instead of the report's own time settings.
• Alerting: The data source supports Grafana Alerting; build alert rules on top of any report or ad-hoc query.
• Dashboard export from DoiT Console: The DoiT Console can generate ready-made Grafana dashboard JSON from any Cloud Analytics dashboard or report for use with this data source.

Requirements

• Grafana 12.3.0 or later.
• A Cloud Intelligence™ account and a DoiT API key with Cloud Analytics access.
• The Grafana Treemap panel plugin for exported dashboards that contain treemap reports.

Configuration

1. In Grafana, go to Connections → Data sources → Add new data source and select DoiT Cloud Intelligence.

2. Set the following options:

   Option	Description
   API URL	DoiT API base URL. Defaults to https://api.doit.com.
   API Key	Your DoiT API key (stored encrypted via Grafana secure JSON data).

3. Click Save & test. The health check verifies connectivity and the API key.

To generate an API key, see the DoiT API documentation.

Provisioning example

apiVersion: 1

datasources:
  - name: DoiT Cloud Intelligence
    type: doitintl-doitcloudintelligence-datasource
    access: proxy
    jsonData:
      apiUrl: https://api.doit.com
    secureJsonData:
      apiKey: $DOIT_API_KEY

Usage

Query a saved report

1. Add a panel and choose the DoiT Cloud Intelligence data source.
2. Set Query type to Saved report.
3. Select a report from the Report drop-down (populated from your DoiT account).
4. Leave Use dashboard time enabled to override the report's time settings with the dashboard time picker, or disable it to use the time range saved in the report.

Ad-hoc query

1. Set Query type to Ad-hoc query.
2. Choose a Metric (cost, usage, or savings) and a Time interval (hour, day, week, or month).
3. Select one or more Group by dimensions (populated from your DoiT account).

Ad-hoc queries total the selected metric over the last 30 days; they do not follow the dashboard time picker. The query editor has no controls for filters or other aggregations. To filter or aggregate differently, create a report in the DoiT Console and query it as a saved report. Ad-hoc queries whose JSON already contains filters or aggregation settings (for example in a provisioned dashboard) are run as configured.

Results are returned as time series frames (one series per group) suitable for time series, bar chart, and stat panels, or as a table for tabular reports. Treemap panels exported by DoiT Console receive a hierarchy frame compatible with the Grafana Treemap panel plugin.

Successful saved-report and ad-hoc query results are cached for six hours per data source instance. Dashboard data can therefore be up to six hours old. API queries run one at a time per data source instance to avoid upstream throttling; additional panel queries wait for the active query to finish. Timed-out queries are not cached; try a shorter time range.

Alerting

The data source supports Grafana Alerting. Create an alert rule, choose this data source in the query, and add expressions (reduce, threshold) as usual.

Getting help

• Open an issue for bugs or feature requests.
• DoiT API reference for the underlying Cloud Analytics API.

Development

See CONTRIBUTING.md for local development, build, and test instructions.

License

Apache-2.0
