Grafana v7.2 released with custom date formats, new transforms and overrides

Published: 23 Sep 2020

The 7.2 stable release builds on the major developments in Grafana 7.0.

Interested in getting started with Grafana? Watch this webinar for a demo of the user interface and setup.

Highlights

New date formatting options added

You can now customize how dates are formatted in Grafana. Custom date formats apply to the time range picker, graphs, and other panel visualizations.

This screenshot shows both a custom full date format with a 12 hour clock and am/pm suffix. The graph is also showing same 12-hour clock format and a customized month and day format compared to the Grafana default MM/DD format.

Custom date time formats

Date formats are set for a Grafana instance by adjusting server-wide settings in the Grafana configuration file. We hope to add org- and user-level settings in the future.

[date_formats]
full_date = MMM Do, YYYY @ hh:mm:ss a
interval_second = hh:mm:ss a
interval_minute = hh:mm a
interval_hour = MMM DD hh:mm a
interval_day = MMM DD
interval_month = YYYY-MM
interval_year = YYYY

There is also experimental support to use the browser location and language to dynamically change the current date format for each user. This feature is disabled by default.

The Configuration topic has been updated as a result of this change.

Field options are out of beta!

After lots of testing and user feedback, we removed the beta label from the configuration options in the Field and Override tabs. This release also includes the following feature enhancements.

Added table column filters

You can now dynamically apply value filters to any table column. This option is can be enabled for all columns or one specific column using an override rule.

Table column filters

New field override selection options

You can now add override rules that use a regex matcher to choose which fields to apply rules to.

The Field options content has been updated as a result of these changes.

New transformations and enhancements

Grafana 7.2 includes the following transformation enhancements:

  • A new Group By transformation that allows you to group by multiple fields and add any number of aggregations for other fields.
  • The Labels to fields transformation now allows you to pick one label and use that as the name of the value field.
  • You can drag transformations to reorder them. Remember that transformations are processed in the order they are listed in the UI, so think before you move something!
Group by and reordering of transformations

Drag to reorder queries

The up and down arrows, which were previously the only way to change query order, have been removed. Instead, there is now a grab icon that allows you to drag and drop queries in a list to change their order.

Drag to reorder queries

Inspect queries in Explore

You can enjoy all the details query inspector gave you in dashboards now in Explore as well. You can open query inspector tab with the button next to query history. See Query inspector in Explore for more details.

$__rate_interval for Prometheus

You can now use the new variable $__rate_interval in Prometheus for rate functions mainly. $__rate_interval in general is one scrape interval larger than $__interval but is never smaller than four times the scrape interval (which is 15s by default). See the Prometheus data source for more details.

Toggle parsed Loki fields

With this awesome contribution from one of our community members, you can now toggle parsed fields in Explore.

Toggling parsed fields in Explore

Sensitive alert channel settings are now encrypted

Alert notification channels now store sensitive settings and secrets, such as API tokens and passwords, encrypted in the database.

Please read the upgrade notes for more information and how to migrate.

Grafana Enterprise features

These features are included in the Grafana Enterprise edition software.

Report and export dashboards in grid layout

A new layout option is available when rendering reports: the grid layout. With this option, your report uses the panel layout from your dashboard, so that what you see is what you get. Learn more about the grid layout in the documentation.

The grid layout is also available for the Export dashboard as PDF feature.

Report time range

You can now generate a report with a different time range from the dashboard it is based on. This means that you no longer have to apply workarounds, such as copying dashboards or carefully aligning report generation with the end of the month, to generate reports that cover the period you want.

For more information, refer to Reports time range.

Organization-wide report settings

You can now configure organization-wide report settings, such as report branding, in the Settings tab on the Reporting page. Settings are applied to all the reports of your current organization.

Reports settings

For more information, refer to Reports settings.

What’s new in other parts of the Grafana ecosystem

ADX (Azure Data Explorer) plugin

In collaboration with Microsoft, we have improved the usability of our ADX datasource plugin by adding a visual query builder. The goal is to make it easier for users, regardless of their previous knowledge of writing KQL (Kusto Query Language) queries, to query and visualize their data.

ADX visual query builder

Upgrading

Refer to Upgrading for more information about upgrading your Grafana installation.

Thank you

A big thanks to all the Grafana users who contributed by submitting PRs, bug reports, and feedback!

Download or try Grafana 7.2 in the cloud today.

Interested in getting started with Grafana? Watch this webinar for a demo of the user interface and setup.
