Get started

This guide assists the reader to create and use a simple Loki cluster. The cluster is intended for testing, development, and evaluation; it will not meet most production requirements.

The test environment runs the flog app to generate log lines. Promtail is the test environment’s agent (or client) that captures the log lines and pushes them to the Loki cluster through a gateway. In a typical environment, the log-generating app and the agent run together, but in locations distinct from the Loki cluster. This guide runs each piece of the test environment locally, in Docker containers.

Grafana provides a way to pose queries against the logs stored in Loki and visualize query results.

The test environment uses Docker compose to instantiate these parts, each in its own container:

One single scalable deployment mode Loki instance has:
- One Loki read component
- One Loki write component
- Minio is Loki’s storage back end in the test environment.
The gateway receives requests and redirects them to the appropriate container based on the request’s URL.
Flog generates log lines.
Promtail scrapes the log lines from flog, and pushes them to Loki through the gateway.
Grafana provides visualization of the log lines captured within Loki.

Prerequisites

Obtain the test environment

Create a directory called evaluate-loki for the test environment. Make evaluate-loki your current working directory:
bash
```
mkdir evaluate-loki
cd evaluate-loki
```

Download loki-config.yaml, promtail-local-config.yaml, and docker-compose.yaml:

wget https://raw.githubusercontent.com/grafana/loki/main/examples/getting-started/loki-config.yaml -O loki-config.yaml
wget https://raw.githubusercontent.com/grafana/loki/main/examples/getting-started/promtail-local-config.yaml -O promtail-local-config.yaml
wget https://raw.githubusercontent.com/grafana/loki/main/examples/getting-started/docker-compose.yaml -O docker-compose.yaml

Deploy the test environment

With evaluate-loki as the current working directory, deploy the test environment using docker-compose:
bash
```
docker-compose up -d
```
(Optional) Verify that the Loki cluster is up and running. The read component returns ready when you point a web browser at http://localhost:3101/ready. The message Query Frontend not ready: not ready: number of schedulers this worker is connected to is 0 will show prior to the read component being ready. The write component returns ready when you point a web browser at http://localhost:3102/ready. The message Ingester not ready: waiting for 15s after being ready will show prior to the write component being ready.

Use Grafana and the test environment

Use Grafana to query and observe the log lines captured in the Loki cluster by navigating a browser to http://localhost:3000. The Grafana instance has Loki configured as a datasource.

Click on the Grafana instance’s Explore icon to bring up the explore pane.

Use the Explore dropdown menu to choose the Loki datasource and bring up the Loki query browser.

Try some queries. Enter your query into the Log browser box, and click on the blue Run query button.

To see all the log lines that flog has generated:

{container="evaluate-loki-flog-1"}

The flog app will generate log lines for invented HTTP requests. To see all GET log lines, enter the query:

{container="evaluate-loki-flog-1"} |= "GET"

For POST methods:

{container="evaluate-loki-flog-1"} |= "POST"

To see every log line with a 401 status (unauthorized error):

{container="evaluate-loki-flog-1"} | json | status="401"

To see every log line other than those that contain the value 401:

{container="evaluate-loki-flog-1"} != "401"

Refer to query examples for more examples.

Stop and clean up the test environment

To break down the test environment:

Close the Grafana browser window
With evaluate-loki as the current working directory, stop and remove all the Docker containers:
bash
```
docker-compose down
```

Modifying the flog app output

You can modify the flog app’s log line generation by changing its configuration. Choose one of these two ways to apply a new configuration:

To remove already-generated logs, restart the test environment with a new configuration.
1. With evaluate-loki as the current working directory, stop and clean up an existing test environment:
```
docker-compose down
```
2. Edit the docker-compose.yaml file. Within the YAML file, change the flog.command field’s value to specify your flog output. Refer to the flog command line arguments.
3. With evaluate-loki as the current working directory, instantiate the new test environment:
```
docker-compose up -d
```
To keep already-generated logs in the running test environment, restart flog with a new configuration.
1. Edit the docker-compose.yaml file. Within the YAML file, change the flog.command field’s value to specify your flog output.
2. With evaluate-loki as the current working directory, restart only the flog app within the currently-running test environment:
```
docker-compose up -d --force-recreate flog
```
