LogQL

Open source

LogQL: Log Query Language

LogQL is Loki’s PromQL-inspired query language. Queries act as if they are a distributed grep to aggregate log sources. LogQL uses labels and operators for filtering.

There are two types of LogQL queries:

Log queries return the contents of log lines.
Metric queries extend log queries to calculate values based on query results.

Log Queries

All LogQL queries contain a log stream selector.

The log stream selector determines how many log streams (unique sources of log content, such as files) will be searched. A more granular log stream selector then reduces the number of searched streams to a manageable volume. This means that the labels passed to the log stream selector will affect the relative performance of the query’s execution.

Optionally, the log stream selector can be followed by a log pipeline. A log pipeline is a set of stage expressions that are chained together and applied to the selected log streams. Each expression can filter out, parse, or mutate log lines and their respective labels.

The following example shows a full log query in action:

{container="query-frontend",namespace="loki-dev"} |= "metrics.go" | logfmt | duration > 10s and throughput_mb < 500

The query is composed of:

a log stream selector {container="query-frontend",namespace="loki-dev"} which targets the query-frontend container in the loki-dev namespace.
a log pipeline |= "metrics.go" | logfmt | duration > 10s and throughput_mb < 500 which will filter out log that contains the word metrics.go, then parses each log line to extract more labels and filter with them.

To avoid escaping special characters you can use the `(backtick) instead of " when quoting strings. For example `\w+` is the same as "\\w+". This is specially useful when writing a regular expression which contains multiple backslashes that require escaping.

Log Stream Selector

The stream selector determines which log streams to include in a query’s results. The stream selector is specified by one or more comma-separated key-value pairs. Each key is a log label and each value is that label’s value. Curly braces ({ and }) delimit the stream selector.

Consider this stream selector:

{app="mysql",name="mysql-backup"}

All log streams that have both a label of app whose value is mysql and a label of name whose value is mysql-backup will be included in the query results. A stream may contain other pairs of labels and values, but only the specified pairs within the stream selector are used to determine which streams will be included within the query results.

The same rules that apply for Prometheus Label Selectors apply for Loki log stream selectors.

The = operator after the label name is a label matching operator. The following label matching operators are supported:

=: exactly equal
!=: not equal
=~: regex matches
!~: regex does not match

Regex log stream examples:

{name =~ "mysql.+"}
{name !~ "mysql.+"}
{name !~ `mysql-\d+`}

Note: The =~ regex operator is fully anchored, meaning regex must match against the entire string, including newlines. The regex . character does not match newlines by default. If you want the regex dot character to match newlines you can use the single-line flag, like so: (?s)search_term.+ matches search_term\n.

Log Pipeline

A log pipeline can be appended to a log stream selector to further process and filter log streams. It usually is composed of one or multiple expressions, each expressions is executed in sequence for each log line. If an expression filters out a log line, the pipeline will stop at this point and start processing the next line.

Some expressions can mutate the log content and respective labels. For example,

| line_format "{{.status_code}}"`)

will be available for further filtering and processing following expressions or metric queries.

A log pipeline can be composed of:

Line Filter Expression
Parser Expression
Label Filter Expression
Line Format Expression
Labels Format Expression
Unwrap Expression. An unwrapped expression is only used within metric queries.

Line Filter Expression

The line filter expression does a distributed grep over the aggregated logs from the matching log streams. It searches the contents of the log line, discarding those lines that do not match the case sensitive expression.

Each line filter expression has a filter operator followed by text or a regular expression. These filter operators are supported:

|=: Log line contains string
!=: Log line does not contain string
|~: Log line contains a match to the regular expression
!~: Log line does not contain a match to the regular expression

Line filter expression examples:

Keep log lines that have the substring “error”:
```
|= "error"
```
A complete query using this example:
```
{job="mysql"} |= "error"
```
Discard log lines that have the substring “kafka.server:type=ReplicaManager”:
```
!= "kafka.server:type=ReplicaManager"
```
A complete query using this example:
```
{instance=~"kafka-[23]",name="kafka"} != "kafka.server:type=ReplicaManager"
```
Keep log lines that contain a substring that starts with tsdb-ops and ends with io:2003. A complete query with a regular expression:
```
{name="kafka"} |~ "tsdb-ops.*io:2003"
```
Keep log lines that contain a substring that starts with error=, and is followed by 1 or more word characters. A complete query with a regular expression:
```
{name="cassandra"} |~  `error=\w+`
```

Filter operators can be chained. Filters are applied sequentially. Query results will have satisfied every filter. This complete query example will give results that include the string error, and do not include the string timeout.

{job="mysql"} |= "error" != "timeout"

When using |~ and !~, Go (as in Golang) RE2 syntax regex may be used. The matching is case-sensitive by default. Switch to case-insensitive matching by prefixing the regular expression with (?i).

While line filter expressions could be placed anywhere within a log pipeline, it is almost always better to have them at the beginning. Placing them at the beginning improves the performance of the query, as it only does further processing when a line matches. For example, while the results will be the same, the query specified with

{job="mysql"} |= "error" | json | line_format "{{.err}}"

will always run faster than

{job="mysql"} | json | line_format "{{.message}}" |= "error"

Line filter expressions are the fastest way to filter logs once the log stream selectors have been applied.

Line filter expressions have support matching IP addresses. See Matching IP addresses for details.

Parser Expression

Parser expression can parse and extract labels from the log content. Those extracted labels can then be used for filtering using label filter expressions or for metric aggregations.

Extracted label keys are automatically sanitized by all parsers, to follow Prometheus metric name convention.(They can only contain ASCII letters and digits, as well as underscores and colons. They cannot start with a digit.)

For instance, the pipeline | json will produce the following mapping:

{ "a.b": {c: "d"}, e: "f" }

{a_b_c="d", e="f"}

In case of errors, for instance if the line is not in the expected format, the log line won’t be filtered but instead will get a new __error__ label added.

If an extracted label key name already exists in the original log stream, the extracted label key will be suffixed with the _extracted keyword to make the distinction between the two labels. You can forcefully override the original label using a label formatter expression. However if an extracted key appears twice, only the latest label value will be kept.

Loki supports JSON, logfmt, pattern, regexp and unpack parsers.

It’s easier to use the predefined parsers json and logfmt when you can. If you can’t, the pattern and regexp parsers can be used for log lines with an unusual structure. The pattern parser is easier and faster to write; it also outperforms the regexp parser. Multiple parsers can be used by a single log pipeline. This is useful for parsing complex logs. There are examples in Multiple parsers.

JSON

The json parser operates in two modes:

without parameters:

Adding | json to your pipeline will extract all json properties as labels if the log line is a valid json document. Nested properties are flattened into label keys using the _ separator.

Note: Arrays are skipped.

For example the json parsers will extract from the following document:

{
    "protocol": "HTTP/2.0",
    "servers": ["129.0.1.1","10.2.1.3"],
    "request": {
        "time": "6.032",
        "method": "GET",
        "host": "foo.grafana.net",
        "size": "55",
        "headers": {
          "Accept": "*/*",
          "User-Agent": "curl/7.68.0"
        }
    },
    "response": {
        "status": 401,
        "size": "228",
        "latency_seconds": "6.031"
    }
}

The following list of labels:

"protocol" => "HTTP/2.0"
"request_time" => "6.032"
"request_method" => "GET"
"request_host" => "foo.grafana.net"
"request_size" => "55"
"response_status" => "401"
"response_size" => "228"
"response_size" => "228"

with parameters:
Using | json label="expression", another="expression" in your pipeline will extract only the specified json fields to labels. You can specify one or more expressions in this way, the same as label_format; all expressions must be quoted.
Currently, we only support field access (my.field, my["field"]) and array access (list[0]), and any combination of these in any level of nesting (my.list[0]["field"]).
For example, | json first_server="servers[0]", ua="request.headers[\"User-Agent\"] will extract from the following document:
json
```
{
    "protocol": "HTTP/2.0",
    "servers": ["129.0.1.1","10.2.1.3"],
    "request": {
        "time": "6.032",
        "method": "GET",
        "host": "foo.grafana.net",
        "size": "55",
        "headers": {
          "Accept": "*/*",
          "User-Agent": "curl/7.68.0"
        }
    },
    "response": {
        "status": 401,
        "size": "228",
        "latency_seconds": "6.031"
    }
}
```
The following list of labels:
kv
```
"first_server" => "129.0.1.1"
"ua" => "curl/7.68.0"
```
If an array or an object returned by an expression, it will be assigned to the label in json format.
For example, | json server_list="servers", headers="request.headers will extract:
kv
```
"server_list" => `["129.0.1.1","10.2.1.3"]`
"headers" => `{"Accept": "*/*", "User-Agent": "curl/7.68.0"}`
```

logfmt

The logfmt parser can be added using the | logfmt and will extract all keys and values from the logfmt formatted log line.

For example the following log line:

at=info method=GET path=/ host=grafana.net fwd="124.133.124.161" service=8ms status=200

will get those labels extracted:

"at" => "info"
"method" => "GET"
"path" => "/"
"host" => "grafana.net"
"fwd" => "124.133.124.161"
"service" => "8ms"
"status" => "200"

Pattern

The pattern parser is a beta feature.

The pattern parser allows the explicit extraction of fields from log lines by defining a pattern expression (| pattern "<pattern-expression>"). The expression matches the structure of a log line.

Consider this NGINX log line.

0.191.12.2 - - [10/Jun/2021:09:14:29 +0000] "GET /api/plugins/versioncheck HTTP/1.1" 200 2 "-" "Go-http-client/2.0" "13.76.247.102, 34.120.177.193" "TLSv1.2" "US" ""

This log line can be parsed with the expression

<ip> - - <_> "<method> <uri> <_>" <status> <size> <_> "<agent>" <_>

to extract these fields:

"ip" => "0.191.12.2"
"method" => "GET"
"uri" => "/api/plugins/versioncheck"
"status" => "200"
"size" => "2"
"agent" => "Go-http-client/2.0"

A pattern expression is composed of captures and literals.

A capture is a field name delimited by the < and > characters. <example> defines the field name example. An unnamed capture appears as <_>. The unnamed capture skips matched content.

Captures are matched from the line beginning or the previous set of literals, to the line end or the next set of literals. If a capture is not matched, the pattern parser will stop.

Literals can be any sequence of UTF-8 characters, including whitespace characters.

By default, a pattern expression is anchored at the start of the log line. If the expression start with literals, then the log line must also start with the same set of literals. Use <_> at the beginning of the expression to anchor the expression at the start.

Consider the log line

level=debug ts=2021-06-10T09:24:13.472094048Z caller=logging.go:66 traceID=0568b66ad2d9294c msg="POST /loki/api/v1/push (204) 16.652862ms"

To match msg=", use the expression:

<_> msg="<method> <path> (<status>) <latency>"

A pattern expression is invalid if

It does not contain any named capture.
It contains two consecutive captures not separated by whitespace characters.

regexp

Unlike the logfmt and json, which extract implicitly all values and takes no parameters, the regexp parser takes a single parameter | regexp "<re>" which is the regular expression using the Golang RE2 syntax.

The regular expression must contain a least one named sub-match (e.g (?P<name>re)), each sub-match will extract a different label.

For example the parser | regexp "(?P<method>\\w+) (?P<path>[\\w|/]+) \\((?P<status>\\d+?)\\) (?P<duration>.*)" will extract from the following line:

POST /api/prom/api/v1/query_range (200) 1.5s

those labels:

"method" => "POST"
"path" => "/api/prom/api/v1/query_range"
"status" => "200"
"duration" => "1.5s"

unpack

The unpack parser will parse a json log line, and unpack all embedded labels via the pack stage. A special property _entry will also be used to replace the original log line.

For example, using | unpack with the following log line:

{
  "container": "myapp",
  "pod": "pod-3223f",
  "_entry": "original log message"
}

allows to extract the container and pod labels and the original log message as the new log line.

You can combine unpack with json parser (or any other parsers) if the original embedded log line is specific format.

Label Filter Expression

Label filter expression allows filtering log line using their original and extracted labels. It can contain multiple predicates.

A predicate contains a label identifier, an operation and a value to compare the label with.

For example with cluster="namespace" the cluster is the label identifier, the operation is = and the value is “namespace”. The label identifier is always on the right side of the operation.

We support multiple value types which are automatically inferred from the query input.

String is double quoted or backticked such as "200" or `us-central1`.
Duration is a sequence of decimal numbers, each with optional fraction and a unit suffix, such as “300ms”, “1.5h” or “2h45m”. Valid time units are “ns”, “us” (or “µs”), “ms”, “s”, “m”, “h”.
Number are floating-point number (64bits), such as250, 89.923.
Bytes is a sequence of decimal numbers, each with optional fraction and a unit suffix, such as “42MB”, “1.5Kib” or “20b”. Valid bytes units are “b”, “kib”, “kb”, “mib”, “mb”, “gib”, “gb”, “tib”, “tb”, “pib”, “pb”, “eib”, “eb”.

String type work exactly like Prometheus label matchers use in log stream selector. This means you can use the same operations (=,!=,=~,!~).

The string type is the only one that can filter out a log line with a label __error__.

Using Duration, Number and Bytes will convert the label value prior to comparision and support the following comparators:

== or = for equality.
!= for inequality.
> and >= for greater than and greater than or equal.
< and <= for lesser than and lesser than or equal.

For instance, logfmt | duration > 1m and bytes_consumed > 20MB

If the conversion of the label value fails, the log line is not filtered and an __error__ label is added. To filters those errors see the pipeline errors section.

You can chain multiple predicates using and and or which respectively express the and and or binary operations. and can be equivalently expressed by a comma, a space or another pipe. Label filters can be place anywhere in a log pipeline.

This means that all the following expressions are equivalent:

| duration >= 20ms or size == 20kb and method!~"2.."
| duration >= 20ms or size == 20kb | method!~"2.."
| duration >= 20ms or size == 20kb , method!~"2.."
| duration >= 20ms or size == 20kb  method!~"2.."

By default the precedence of multiple predicates is right to left. You can wrap predicates with parenthesis to force a different precedence left to right.

For example the following are equivalent.

| duration >= 20ms or method="GET" and size <= 20KB
| ((duration >= 20ms or method="GET") and size <= 20KB)

It will evaluate first duration >= 20ms or method="GET". To evaluate first method="GET" and size <= 20KB, make sure to use proper parenthesis as shown below.

| duration >= 20ms or (method="GET" and size <= 20KB)

Label filter expressions are the only expression allowed after the unwrap expression. This is mainly to allow filtering errors from the metric extraction (see errors).

Label filter expressions have support matching IP addresses. See Matching IP addresses for details.

Line Format Expression

The line format expression can rewrite the log line content by using the text/template format. It takes a single string parameter | line_format "{{.label_name}}", which is the template format. All labels are injected variables into the template and are available to use with the {{.label_name}} notation.

For example the following expression:

{container="frontend"} | logfmt | line_format "{{.query}} {{.duration}}"

Will extract and rewrite the log line to only contains the query and the duration of a request.

You can use double quoted string for the template or backticks `{{.label_name}}` to avoid the need to escape special characters.

line_format also supports math functions. Example:

If we have the following labels ip=1.1.1.1, status=200 and duration=3000(ms), we can divide the duration by 1000 to get the value in seconds.

{container="frontend"} | logfmt | line_format "{{.ip}} {{.status}} {{div .duration 1000}}"

The above query will give us the line as 1.1.1.1 200 3

See template functions to learn about available functions in the template format.

Labels Format Expression

The | label_format expression can rename, modify or add labels. It takes as parameter a comma separated list of equality operations, enabling multiple operations at once.

When both side are label identifiers, for example dst=src, the operation will rename the src label into dst.

The left side can alternatively be a template string (double quoted or backtick), for example dst="{{.status}} {{.query}}", in which case the dst label value is replaced by the result of the text/template evaluation. This is the same template engine as the | line_format expression, which means labels are available as variables and you can use the same list of functions.

In both cases, if the destination label doesn’t exist, then a new one is created.

The renaming form dst=src will drop the src label after remapping it to the dst label. However, the template form will preserve the referenced labels, such that dst="{{.src}}" results in both dst and src having the same value.

A single label name can only appear once per expression. This means | label_format foo=bar,foo="new" is not allowed but you can use two expressions for the desired effect: | label_format foo=bar | label_format foo="new"

Log Queries Examples

Multiple filtering

Filtering should be done first using label matchers, then line filters (when possible) and finally using label filters. The following query demonstrate this.

{cluster="ops-tools1", namespace="loki-dev", job="loki-dev/query-frontend"} |= "metrics.go" !="out of order" | logfmt | duration > 30s or status_code!="200"

Multiple parsers

To extract the method and the path of the following logfmt log line:

level=debug ts=2020-10-02T10:10:42.092268913Z caller=logging.go:66 traceID=a9d4d8a928d8db1 msg="POST /api/prom/api/v1/query_range (200) 1.5s"

You can use multiple parsers (logfmt and regexp) like this.

{job="cortex-ops/query-frontend"} | logfmt | line_format "{{.msg}}" | regexp "(?P<method>\\w+) (?P<path>[\\w|/]+) \\((?P<status>\\d+?)\\) (?P<duration>.*)"

This is possible because the | line_format reformats the log line to become POST /api/prom/api/v1/query_range (200) 1.5s which can then be parsed with the | regexp ... parser.

Formatting

The following query shows how you can reformat a log line to make it easier to read on screen.

{cluster="ops-tools1", name="querier", namespace="loki-dev"}
  |= "metrics.go" != "loki-canary"
  | logfmt
  | query != ""
  | label_format query="{{ Replace .query \"\\n\" \"\" -1 }}"
  | line_format "{{ .ts}}\t{{.duration}}\ttraceID = {{.traceID}}\t{{ printf \"%-100.100s\" .query }} "

Label formatting is used to sanitize the query while the line format reduce the amount of information and creates a tabular output.

For those given log line:

level=info ts=2020-10-23T20:32:18.094668233Z caller=metrics.go:81 org_id=29 traceID=1980d41501b57b68 latency=fast query="{cluster=\"ops-tools1\", job=\"cortex-ops/query-frontend\"} |= \"query_range\"" query_type=filter range_type=range length=15m0s step=7s duration=650.22401ms status=200 throughput_mb=1.529717 total_bytes_mb=0.994659
level=info ts=2020-10-23T20:32:18.068866235Z caller=metrics.go:81 org_id=29 traceID=1980d41501b57b68 latency=fast query="{cluster=\"ops-tools1\", job=\"cortex-ops/query-frontend\"} |= \"query_range\"" query_type=filter range_type=range length=15m0s step=7s duration=624.008132ms status=200 throughput_mb=0.693449 total_bytes_mb=0.432718

The result would be:

2020-10-23T20:32:18.094668233Z	650.22401ms	    traceID = 1980d41501b57b68	{cluster="ops-tools1", job="cortex-ops/query-frontend"} |= "query_range"
2020-10-23T20:32:18.068866235Z	624.008132ms	traceID = 1980d41501b57b68	{cluster="ops-tools1", job="cortex-ops/query-frontend"} |= "query_range"

Metric Queries

LogQL supports applying a function to log query results. This powerful feature creates metrics from logs.

Metric queries can be used to calculate things such as the rate of error messages, or the top N log sources with the most amount of logs over the last 3 hours.

Combined with log parsers, metrics queries can also be used to calculate metrics from a sample value within the log line, such as latency or request size. All labels, including extracted ones, will be available for aggregations and generation of new series.

Range Vector aggregation

LogQL shares the range vector concept of Prometheus. In Loki, the selected range of samples is a range of selected log or label values.

The aggregation is applied over a time duration. Loki defines Time Durations with the same syntax as Prometheus.

Loki supports two types of range vector aggregations: log range aggregations and unwrapped range aggregations.

Log Range Aggregations

A log range aggregation is a query followed by a duration. A function is applied to aggregate the query over the duration. The duration can be placed after the log stream selector or at end of the log pipeline.

The functions:

rate(log-range): calculates the number of entries per second
count_over_time(log-range): counts the entries for each log stream within the given range.
bytes_rate(log-range): calculates the number of bytes per second for each stream.
bytes_over_time(log-range): counts the amount of bytes used by each log stream for a given range.
absent_over_time(log-range): returns an empty vector if the range vector passed to it has any elements and a 1-element vector with the value 1 if the range vector passed to it has no elements. (absent_over_time is useful for alerting on when no time series and logs stream exist for label combination for a certain amount of time.)

Examples:

Count all the log lines within the last five minutes for the MySQL job.
logql
```
count_over_time({job="mysql"}[5m])
```
This aggregation includes filters and parsers. It returns the per-second rate of all non-timeout errors within the last minutes per host for the MySQL job and only includes errors whose duration is above ten seconds.
logql
```
sum by (host) (rate({job="mysql"} |= "error" != "timeout" | json | duration > 10s [1m]))
```

Unwrapped Range Aggregations

Unwrapped ranges uses extracted labels as sample values instead of log lines. However to select which label will be used within the aggregation, the log query must end with an unwrap expression and optionally a label filter expression to discard errors.

The unwrap expression is noted | unwrap label_identifier where the label identifier is the label name to use for extracting sample values.

Since label values are string, by default a conversion into a float (64bits) will be attempted, in case of failure the __error__ label is added to the sample. Optionally the label identifier can be wrapped by a conversion function | unwrap <function>(label_identifier), which will attempt to convert the label value from a specific format.

We currently support the functions:

duration_seconds(label_identifier) (or its short equivalent duration) which will convert the label value in seconds from the go duration format (e.g 5m, 24s30ms).
bytes(label_identifier) which will convert the label value to raw bytes applying the bytes unit (e.g. 5 MiB, 3k, 1G).

Supported function for operating over unwrapped ranges are:

rate(unwrapped-range): calculates per second rate of all values in the specified interval.
sum_over_time(unwrapped-range): the sum of all values in the specified interval.
avg_over_time(unwrapped-range): the average value of all points in the specified interval.
max_over_time(unwrapped-range): the maximum value of all points in the specified interval.
min_over_time(unwrapped-range): the minimum value of all points in the specified interval
first_over_time(unwrapped-range): the first value of all points in the specified interval
last_over_time(unwrapped-range): the last value of all points in the specified interval
stdvar_over_time(unwrapped-range): the population standard variance of the values in the specified interval.
stddev_over_time(unwrapped-range): the population standard deviation of the values in the specified interval.
quantile_over_time(scalar,unwrapped-range): the φ-quantile (0 ≤ φ ≤ 1) of the values in the specified interval.
absent_over_time(unwrapped-range): returns an empty vector if the range vector passed to it has any elements and a 1-element vector with the value 1 if the range vector passed to it has no elements. (absent_over_time is useful for alerting on when no time series and logs stream exist for label combination for a certain amount of time.)

Except for sum_over_time,absent_over_time and rate, unwrapped range aggregations support grouping.

<aggr-op>([parameter,] <unwrapped-range>) [without|by (<label list>)]

Which can be used to aggregate over distinct labels dimensions by including a without or by clause.

without removes the listed labels from the result vector, while all other labels are preserved the output. by does the opposite and drops labels that are not listed in the by clause, even if their label values are identical between all elements of the vector.

Unwrapped Examples

quantile_over_time(0.99,
  {cluster="ops-tools1",container="ingress-nginx"}
    | json
    | __error__ = ""
    | unwrap request_time [1m])) by (path)

This example calculates the p99 of the nginx-ingress latency by path.

sum by (org_id) (
  sum_over_time(
  {cluster="ops-tools1",container="loki-dev"}
      |= "metrics.go"
      | logfmt
      | unwrap bytes_processed [1m])
  )

This calculates the amount of bytes processed per organization id.

Aggregation operators

Like PromQL, LogQL supports a subset of built-in aggregation operators that can be used to aggregate the element of a single vector, resulting in a new vector of fewer elements but with aggregated values:

sum: Calculate sum over labels
min: Select minimum over labels
max: Select maximum over labels
avg: Calculate the average over labels
stddev: Calculate the population standard deviation over labels
stdvar: Calculate the population standard variance over labels
count: Count number of elements in the vector
bottomk: Select smallest k elements by sample value
topk: Select largest k elements by sample value

The aggregation operators can either be used to aggregate over all label values or a set of distinct label values by including a without or a by clause:

<aggr-op>([parameter,] <vector expression>) [without|by (<label list>)]

parameter is only required when using topk and bottomk. topk and bottomk are different from other aggregators in that a subset of the input samples, including the original labels, are returned in the result vector.

by and without are only used to group the input vector. The without clause removes the listed labels from the resulting vector, keeping all others. The by clause does the opposite, dropping labels that are not listed in the clause, even if their label values are identical between all elements of the vector.

Vector Aggregations Examples

Get the top 10 applications by the highest log throughput:

topk(10,sum(rate({region="us-east1"}[5m])) by (name))

Get the count of logs for the last five minutes, grouping by level:

sum(count_over_time({job="mysql"}[5m])) by (level)

Get the rate of HTTP GET of /home requests from NGINX logs by region:

avg(rate(({job="nginx"} |= "GET" | json | path="/home")[10s])) by (region)

Functions

Loki supports several functions to operate on data. These are described in detail in the expression language functions page.

Binary Operators

Arithmetic Binary Operators

The following binary arithmetic operators exist in Loki:

+ (addition)
- (subtraction)
* (multiplication)
/ (division)
% (modulo)
^ (power/exponentiation)

Binary arithmetic operators are defined between two literals (scalars), a literal and a vector, and two vectors.

Between two literals, the behavior is obvious: They evaluate to another literal that is the result of the operator applied to both scalar operands (1 + 1 = 2).

Between a vector and a literal, the operator is applied to the value of every data sample in the vector, e.g. if a time series vector is multiplied by 2, the result is another vector in which every sample value of the original vector is multiplied by 2.

Between two vectors, a binary arithmetic operator is applied to each entry in the left-hand side vector and its matching element in the right-hand vector. The result is propagated into the result vector with the grouping labels becoming the output label set. Entries for which no matching entry in the right-hand vector can be found are not part of the result.

Pay special attention to operator order when chaining arithmetic operators.

Arithmetic Examples

Implement a health check with a simple query:

1 + 1

Double the rate of a a log stream’s entries:

sum(rate({app="foo"})) * 2

Get proportion of warning logs to error logs for the foo app

sum(rate({app="foo", level="warn"}[1m])) / sum(rate({app="foo", level="error"}[1m]))

Logical/set binary operators

These logical/set binary operators are only defined between two vectors:

and (intersection)
or (union)
unless (complement)

vector1 and vector2 results in a vector consisting of the elements of vector1 for which there are elements in vector2 with exactly matching label sets. Other elements are dropped.

vector1 or vector2 results in a vector that contains all original elements (label sets + values) of vector1 and additionally all elements of vector2 which do not have matching label sets in vector1.

vector1 unless vector2 results in a vector consisting of the elements of vector1 for which there are no elements in vector2 with exactly matching label sets. All matching elements in both vectors are dropped.

Binary Operators Examples

This contrived query will return the intersection of these queries, effectively rate({app="bar"}):

rate({app=~"foo|bar"}[1m]) and rate({app="bar"}[1m])

Comparison operators

== (equality)
!= (inequality)
> (greater than)
>= (greater than or equal to)
< (less than)
<= (less than or equal to)

Comparison operators are defined between scalar/scalar, vector/scalar, and vector/vector value pairs. By default they filter. Their behavior can be modified by providing bool after the operator, which will return 0 or 1 for the value rather than filtering.

Between two scalars, these operators result in another scalar that is either 0 (false) or 1 (true), depending on the comparison result. The bool modifier must not be provided.

1 >= 1 is equivalent to 1

Between a vector and a scalar, these operators are applied to the value of every data sample in the vector, and vector elements between which the comparison result is false get dropped from the result vector. If the bool modifier is provided, vector elements that would be dropped instead have the value 0 and vector elements that would be kept have the value 1.

Filters the streams which logged at least 10 lines in the last minute:

count_over_time({foo="bar"}[1m]) > 10

Attach the value(s) 0/1 to streams that logged less/more than 10 lines:

count_over_time({foo="bar"}[1m]) > bool 10

Between two vectors, these operators behave as a filter by default, applied to matching entries. Vector elements for which the expression is not true or which do not find a match on the other side of the expression get dropped from the result, while the others are propagated into a result vector. If the bool modifier is provided, vector elements that would have been dropped instead have the value 0 and vector elements that would be kept have the value 1, with the grouping labels again becoming the output label set.

Return the streams matching app=foo without app labels that have higher counts within the last minute than their counterparts matching app=bar without app labels:

sum without(app) (count_over_time({app="foo"}[1m])) > sum without(app) (count_over_time({app="bar"}[1m]))

Same as above, but vectors have their values set to 1 if they pass the comparison or 0 if they fail/would otherwise have been filtered out:

sum without(app) (count_over_time({app="foo"}[1m])) > bool sum without(app) (count_over_time({app="bar"}[1m]))

Operator order

When chaining or combining operators, you have to consider operator precedence: Generally, you can assume regular mathematical convention with operators on the same precedence level being left-associative.

More details can be found in the Golang language documentation.

1 + 2 / 3 is equal to 1 + ( 2 / 3 ).

2 * 3 % 2 is evaluated as (2 * 3) % 2.

Comments

LogQL queries can be commented using the # character:

{app="foo"} # anything that comes after will not be interpreted in your query

With multi-line LogQL queries, the query parser can exclude whole or partial lines using #:

{app="foo"}
    | json
    # this line will be ignored
    | bar="baz" # this checks if bar = "baz"

Pipeline Errors

There are multiple reasons which cause pipeline processing errors, such as:

A numeric label filter may fail to turn a label value into a number
A metric conversion for a label may fail.
A log line is not a valid json document.
etc…

When those failures happen, Loki won’t filter out those log lines. Instead they are passed into the next stage of the pipeline with a new system label named __error__. The only way to filter out errors is by using a label filter expressions. The __error__ label can’t be renamed via the language.

For example to remove json errors:

  {cluster="ops-tools1",container="ingress-nginx"}
    | json
    | __error__ != "JSONParserErr"

Alternatively you can remove all error using a catch all matcher such as __error__ = "" or even show only errors using __error__ != "".

The filter should be placed after the stage that generated this error. This means if you need to remove errors from an unwrap expression it needs to be placed after the unwrap.

quantile_over_time(
	0.99,
	{container="ingress-nginx",service="hosted-grafana"}
	| json
	| unwrap response_latency_seconds
	| __error__=""[1m]
	) by (cluster)

Metric queries cannot contains errors, in case errors are found during execution, Loki will return an error and appropriate status code.

Was this page helpful?

Create a GitHub issue

Email docs@grafana.com

Help and support

Community

Feedback

Relevant sources:

Feedback

LogQL: Log Query Language

Log Queries

Log Stream Selector

Log Pipeline

Line Filter Expression

Parser Expression

JSON

logfmt

Pattern

regexp

unpack

Label Filter Expression

Line Format Expression

Labels Format Expression

Log Queries Examples

Multiple filtering

Multiple parsers

Formatting

Metric Queries

Range Vector aggregation

Log Range Aggregations

Unwrapped Range Aggregations

Unwrapped Examples

Aggregation operators

Vector Aggregations Examples

Functions

Binary Operators

Arithmetic Binary Operators

Arithmetic Examples

Logical/set binary operators

Binary Operators Examples

Comparison operators

Operator order

Comments

Pipeline Errors

Was this page helpful?

Related documentation

LogQL: Log Query Language

Log Queries

Log Stream Selector

Log Pipeline

Line Filter Expression

Parser Expression

JSON

logfmt

Pattern

regexp

unpack

Label Filter Expression

Line Format Expression

Labels Format Expression

Log Queries Examples

Multiple filtering

Multiple parsers

Formatting

Metric Queries

Range Vector aggregation

Log Range Aggregations

Unwrapped Range Aggregations

Unwrapped Examples

Aggregation operators

Vector Aggregations Examples

Functions

Binary Operators

Arithmetic Binary Operators

Arithmetic Examples

Logical/set binary operators

Binary Operators Examples

Comparison operators

Operator order

Comments

Pipeline Errors

Was this page helpful?

Related documentation

Related resources from Grafana Labs
