Hp ilo

HP iLO Metrics Exporter The information displayed in this dashboard ‍‍‍‍

Hp ilo screenshot 1
Hp ilo screenshot 2
Hp ilo screenshot 3

HP iLO Metrics Exporter

Output Example of status of your iLO

health_at_a_glance:

  battery: {status: OK}
  bios_hardware: {status: OK}
  fans: {redundancy: Redundant, status: OK}
  memory: {status: OK}
  network: {status: Link Down},
  power_supplies: {redundancy: Redundant, status: OK}
  processor: {status: OK}
  storage: {status: Degraded}
  temperature: {status: OK}
  vrm: {status: Ok}
  drive: {status: Ok}

The returned output would be:

hpilo_battery{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 0.0
hpilo_storage{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 1.0
hpilo_fans{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 0.0
hpilo_bios_hardware{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 0.0
hpilo_memory{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 0.0
hpilo_power_supplies{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 0.0
hpilo_processor{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 0.0
hpilo_network{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 2.0
hpilo_temperature{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 0.0
hpilo_vrm{product_name="ProLiant DL380 Gen6",server_name="name.fqdn.domain"} 0.0
hpilo_drive{product_name="ProLiant DL380 Gen6",server_name="name.fqdn.domain"} 0.0
hpilo_firmware_version{product_name="ProLiant DL360 Gen9",server_name="name.fqdn.domain"} 2.5

more infor: https://github.com/greenweb-cloud/prometheus_exporters/tree/main/hpilo-exporter
